Overview
This vignette shows the univariate workflow implemented in
dyadicMarkov. In the univariate setting, one categorical
variable is observed repeatedly for the two members of a dyad. The
workflow follows the single-case method described in Bollenrücher et al. (2023): empirical transition
counts are computed from the dyadic sequence, transition probabilities
are estimated by maximum likelihood, and restricted actor/partner
structures are compared to identify the pattern of interaction.
The example uses the data set dyadic_univariate_example
included in the package. The data are synthetic and are used only to
illustrate the required input structure and the package workflow.
Although the data are synthetic, the two columns can be read like
real ordered observations from a dyad. For example, FM and
SM could represent two partners, a parent and child, a
therapist and client, or any two interacting members observed at
repeated occasions. The integer states represent coded categories of a
behavior or response. In a binary application, state 1 and state 2 could
represent absence and presence of a coded behavior, two interaction
states, or two response categories defined by the researcher.
Data
The univariate example contains one categorical variable for the
first member (FM) and the second member (SM)
of a dyad. Each row corresponds to one measurement occasion. In the
first analysis, FM is the first member sequence analyzed
and SM is the second member sequence.
utils::data("dyadic_univariate_example", package = "dyadicMarkov")
head(dyadic_univariate_example)
#> time FM SM
#> 1 1 2 1
#> 2 2 2 1
#> 3 3 1 2
#> 4 4 1 1
#> 5 5 1 1
#> 6 6 2 1
dim(dyadic_univariate_example)
#> [1] 90 3The states are integer-coded. In this example, both members can take the values 1 or 2.
Empirical transition counts
The first step is to compute empirical transition counts with
countEmp(). For states = 2, the rows represent
the four possible previous dyadic states (FM_t, SM_t), and
the columns represent the state of the first member at the next time
point, FM_{t+1}.
emp_uni <- dyadicMarkov::countEmp(
chainFM = dyadic_univariate_example$FM,
chainSM = dyadic_univariate_example$SM,
states = 2L
)
emp_uni
#> next_1 next_2
#> FM1_SM1 26 4
#> FM1_SM2 5 14
#> FM2_SM1 12 5
#> FM2_SM2 7 16
class(emp_uni)
#> [1] "dyadic_counts" "matrix" "array"The resulting object keeps ordinary matrix behavior.
Maximum-likelihood transition probabilities
The empirical counts can be converted into transition probabilities
using mleEstimation(). Rows with positive totals are
normalized independently. For an unobserved previous-state combination,
the transition probabilities are unidentified; the package returns a
uniform row as an implementation convention.
fit_uni <- dyadicMarkov::mleEstimation(emp_uni)
round(fit_uni, 3)
#> next_1 next_2
#> FM1_SM1 0.867 0.133
#> FM1_SM2 0.263 0.737
#> FM2_SM1 0.706 0.294
#> FM2_SM2 0.304 0.696
rowSums(fit_uni)
#> FM1_SM1 FM1_SM2 FM2_SM1 FM2_SM2
#> 1 1 1 1
class(fit_uni)
#> [1] "dyadic_mle" "matrix" "array"The estimated transition matrix summarizes the empirical transition structure of the observed dyadic sequence.
Univariate pattern identification
The function univariatePattern() performs the univariate
identification step. It compares the unrestricted actor-partner
structure with actor-only and partner-only restricted structures through
likelihood-ratio tests. The two test outcomes are then combined to
classify the sequence as Actor-Partner, Actor-only, Partner-only or
Independence.
pat_uni <- dyadicMarkov::univariatePattern(
chainFM = dyadic_univariate_example$FM,
chainSM = dyadic_univariate_example$SM,
states = 2L,
alpha = 0.05
)
pat_uni
#> Dyadic interaction pattern
#> Pattern: PM (A3)
#> Alpha: 0.05
#> States: 2For this example, the selected pattern is stored in the
pattern component.
pat_uni$pattern
#> [1] "PM (A3)"
pat_uni$TEST.AM
#>
#> Likelihood-ratio test, Actor-only model
#>
#> data: Observed vs Estimated
#> X-squared = 24.551, df = 2, p-value = 4.666e-06
#> alternative hypothesis: The unrestricted model fits the data better
pat_uni$TEST.PM
#>
#> Likelihood-ratio test, Partner-only model
#>
#> data: Observed vs Estimated
#> X-squared = 1.8984, df = 2, p-value = 0.3871
#> alternative hypothesis: The unrestricted model fits the data better
summary(pat_uni)
#> $pattern
#> [1] "PM (A3)"
#>
#> $alpha
#> [1] 0.05
#>
#> $states
#> [1] 2
#>
#> $call
#> dyadicMarkov::univariatePattern(chainFM = dyadic_univariate_example$FM,
#> chainSM = dyadic_univariate_example$SM, states = 2L, alpha = 0.05)
#>
#> attr(,"class")
#> [1] "summary_dyadic_pattern" "list"The returned object is a list with an additional S3 class. It can therefore be printed and summarized, while still allowing direct access to its components.
Interpretation
In this example, the selected pattern is PM (A3). This
indicates that the previous state of the second member is retained in
the restricted structure, whereas the previous state of the first member
is not retained. In the terminology of the univariate method, this
corresponds to a partner-only pattern.
The result should be interpreted as a pattern description for the
member sequence analyzed by the function. The function call above
analyzes FM as the first member sequence and
SM as the second member sequence. Reversing the two
arguments analyzes the sequence from the perspective of the second
member. Thus, describing both members of a dyad requires two calls, and
each returned pattern is specific to the member sequence analyzed.
pat_uni_reverse <- dyadicMarkov::univariatePattern(
chainFM = dyadic_univariate_example$SM,
chainSM = dyadic_univariate_example$FM,
states = 2L,
alpha = 0.05
)
pat_uni_reverse
#> Dyadic interaction pattern
#> Pattern: PM (A3)
#> Alpha: 0.05
#> States: 2
